What Are the Main Types of Screw Pumps and How Do They Differ?

Screw pumps are a group of positive displacement pumps that use one or more rotating screws to move fluids

along the pump axis. They are widely used in oil and gas, chemical processing, power generation, marine, food and beverage,

and many other industries where reliable, low-pulsation flow is required.

This guide explains the main types of screw pumps, how they work, key differences, advantages, limitations,

and typical applications. It is written in clear technical English and structured for strong search engine visibility with

keyword-rich headings and tables.

1. Overview: What Is a Screw Pump?

A screw pump is a rotary positive displacement pump in which fluid is transported by the rotation of one or

more screws inside a sealed cavity. As the screws rotate, they form chambers that capture the fluid at the suction side and

continuously move it to the discharge side with smooth, nearly pulsation-free flow.

1.1 Key Characteristics of Screw Pumps

• Positive displacement pumping principle
• One or more helical screws as the pumping elements
• Axial flow of the pumped liquid
• Low pulsation and low noise compared with many other positive displacement pumps
• Ability to handle a wide range of viscosities
• Self-priming capability in most designs
• High efficiency and long service life when properly selected and maintained

1.2 Main Screw Pump Categories

Industry practice usually divides screw pumps into the following main types:

• Single screw pumps (progressive cavity pumps)
• Twin screw pumps (two-screw pumps)
• Three screw pumps
• Four screw and multi screw pumps

All of these are multi-rotor positive displacement pumps except the classic single screw pump, which uses

one rotor and a matching stator. Each type of screw pump has specific strengths that make it more suitable for particular

fluids, pressures, temperatures, and operating conditions.

2. Common Features of Screw Pump Technology

Before looking at the differences between the main types of screw pumps, it is useful to understand what they all have in

common from a design and performance perspective.

2.1 Positive Displacement Principle

• Fixed displacement per revolution (within slip and leakage limits)
• Flow rate is roughly proportional to speed, relatively independent of discharge pressure
• Must include pressure relief or safety devices to avoid overpressure

2.2 Advantages of Screw Pumps

• Very smooth, low-pulsation flow suitable for sensitive processes
• Good self-priming capabilities
• Can handle high viscosities and shear-sensitive liquids (depending on type)
• Low noise and vibration at appropriate speeds
• Can achieve medium to high pressures with high efficiency
• Line contact or small clearances between screws support high volumetric efficiency

2.3 Typical Limitations

• More complex machining and tighter tolerances than simple gear pumps
• Lower tolerance for large solid particles in most designs
• Clearances and slip strongly affected by wear and contamination
• Need controlled operating speed to minimize wear and maintain efficiency

3. Single Screw Pumps (Progressive Cavity Pumps)

A single screw pump, commonly called a progressive cavity pump (PC pump), consists of:

• A single helical metal rotor (screw)
• A double-helix elastomer stator with an internal cavity

As the rotor turns inside the stator, progressing cavities are formed that move axially from suction to

discharge. The fluid is trapped in these sealed cavities and transported with little shear.

3.1 Working Principle

1. Rotor, shaped like a single-start helical screw, rotates eccentrically inside the stator.
2. The stator has a double helix with a slightly larger pitch and diameter.
3. This geometry creates cavities that form, move, and disappear as the rotor turns.
4. Fluid fills these cavities at the suction side and is gently pushed toward the discharge.

3.2 Key Features of Single Screw / Progressive Cavity Pumps

• Excellent handling of highly viscous and non-Newtonian fluids
• Very good performance with shear-sensitive products
• Can reliably pump fluids with solids, fibers, or abrasive particles when designed correctly
• Relatively low operating speed, reducing shear and wear
• Used widely in wastewater, sludge handling, food pastes, paints, and polymer solutions

3.3 Advantages of Single Screw Pumps

• Very gentle pumping, preserving product structure
• Handles sludges, slurries, and multiphase flows with entrained air
• Self-priming with ability to run at low NPSH conditions when configured properly
• Steady, low-pulsation flow suitable for dosing and metering (with speed control)

3.4 Limitations of Single Screw Pumps

• Elastomer stator limits operating temperature and chemical compatibility
• Lower maximum pressures compared with multi-screw metal pumps in similar sizes
• Stator wear is significant when handling highly abrasive slurries
• Requires careful alignment and shaft sealing to prevent dry running damage

3.5 Typical Applications of Progressive Cavity Screw Pumps

• Wastewater treatment: sludge, slurry, and thickened sludge transfer
• Food and beverage: dough, syrups, fruit pulps, chocolate, sauces
• Chemical and polymer processes: polymers, resins, latex, adhesives
• Mining: tailings, thickened slurry, paste backfill
• Oil and gas: multiphase production, heavy crude, emulsions

4. Twin Screw Pumps (Two-Screw Pumps)

A twin screw pump uses two intermeshing screws that rotate in opposite directions, either driven directly

by a timing gear or hydraulically balanced by pressure forces. Twin screw pumps are commonly used where

bi-directional flow, high suction capability, and low pulsation are important.

4.1 Working Principle

1. Two parallel screws with helical threads mesh inside a close-fitting housing.
2. As the screws rotate, they form sealed chambers between the screw flanks and the housing.
3. These chambers move axially from the suction side to the discharge side.
4. Fluid is carried in these chambers with minimal turbulence and pulsation.

4.2 Dry-Running Capability (Timing Gear Type)

In many twin screw pump designs, timing gears keep the screws synchronized so they do not touch each other.

This allows:

• Dry running for short periods without damage (depending on seals and bearings)
• Handling of gas-liquid mixtures and multiphase fluids
• Very low NPSH operation and strong suction performance

4.3 Key Features of Twin Screw Pumps

• Can handle low to very high viscosities (from thin solvents to heavy oils)
• Very smooth, low-pulsation flow and low noise
• Often capable of bi-directional operation (reversible flow)
• Suitable for CIP (clean-in-place) in hygienic versions
• Available in designs for sanitary, chemical, and marine applications

4.4 Advantages of Twin Screw Pumps

• Excellent suction performance, useful for stripping tanks and pipelines
• Can handle entrained gas and multiphase mixtures better than many other PD pumps
• Minimal shear, gentle on sensitive products
• Wide viscosity range without mechanical modification
• Can be used as process and CIP pump in one unit in hygienic industries

4.5 Limitations of Twin Screw Pumps

• More complex and expensive than simple gear or lobe pumps
• Requires precise manufacturing to maintain clearances and efficiency
• Less tolerant of large hard solids; best with clean or mildly contaminated liquids
• Size and speed must be carefully selected to avoid cavitation and wear

4.6 Typical Applications of Twin Screw Pumps

• Oil and gas: loading/unloading, pipeline transfer, multiphase pumping
• Marine: fuel oil transfer, lube oil supply, ballast, and stripping duties
• Food and beverage: dairy products, beverages, sauces, creams, chocolate
• Chemical and petrochemical: solvents, polymers, resins, and additives
• Power generation: fuel and lube oil systems

5. Three Screw Pumps

A three screw pump is a compact, efficient internal bearing screw pump type primarily used

for lubricating and hydraulic oils. It uses:

• One driving screw (power rotor)
• Two driven screws (idler rotors)

These three screws mesh together and rotate inside a close-fitting housing. The pumped liquid provides

hydrodynamic lubrication for the screws and bearings.

5.1 Working Principle

1. The driving screw is connected to the motor or gear drive.
2. As the driving screw rotates, it transmits torque to the two idler screws through hydrodynamic film and/or direct contact.
3. The screw flanks create sealed cavities that move axially, carrying the fluid from suction to discharge.
4. The pumped liquid lubricates the contact surfaces, minimizing wear.

5.2 Key Features of Three Screw Pumps

• Designed primarily for clean, lubricating fluids
• High efficiency at medium to high discharge pressures
• Simple, compact design with only one shaft seal in many configurations
• Very low noise and pulsation, ideal for sensitive hydraulic systems

5.3 Advantages of Three Screw Pumps

• Excellent for lubricating oils and fuels
• Capable of relatively high pressures in compact sizes
• Long service life when operated within design limits
• High reliability and low maintenance in continuous service

5.4 Limitations of Three Screw Pumps

• Not suitable for fluids with solids or abrasive particles
• Performance depends strongly on fluid lubricity and cleanliness
• Limited viscosity range compared with twin screw pumps
• Internal bearings require the pumped fluid to provide lubrication

5.5 Typical Applications of Three Screw Pumps

• Lube oil circulation in turbines, compressors, and gearboxes
• Hydraulic power units and hydraulic presses
• Fuel oil transfer and burner feed systems
• Machine tool lubrication and coolant systems
• Power generation and marine engine lubrication

6. Four Screw and Multi Screw Pumps

Beyond single, twin, and three screw pumps, the industry also uses four screw pumps and other

multi screw pump designs. These are typically used for higher capacities or specific fluid conditions.

6.1 Four Screw Pumps

Four screw pumps usually have:

• Two pairs of screws (four screws total) arranged in parallel
• Each pair functioning similarly to a twin screw pump
• Torque transmitted through timing gears or hydraulic balancing

By using four screws, the pump can increase flow capacity while maintaining relatively low speeds and

excellent suction characteristics.

6.2 Multi Screw Pump Concept

The term multi screw pump is often used generically to describe any pump with more than one screw:

• Twin screw pumps (2 screws)
• Three screw pumps (3 screws)
• Four screw pumps (4 screws)

Multi screw pumps share similar features:

• Axial flow of the liquid
• Very smooth, nearly pulsation-free discharge
• Capability to handle medium to high pressures
• Use of intermeshing screws with close clearances

6.3 Typical Applications of Four and Multi Screw Pumps

• Large-volume oil transfer and loading
• Pipeline boosting in oil and gas systems
• Refinery and petrochemical processes
• Tank farm circulation and terminal operations
• Power plant fuel oil systems

7. Comparison of Main Screw Pump Types

The table below summarizes the main differences between single screw, twin screw, three screw, and four screw pumps.

8. Working Principles in More Detail

Although all screw pumps are positive displacement devices, their internal geometry and flow patterns differ. Understanding

these differences helps in choosing the right type of screw pump for specific duties.

8.1 Axial Flow and Sealed Cavities

• The key common element is the creation of sealed cavities that move axially.
• For multi screw pumps, these cavities are formed between meshing screw flanks and the casing.
• For progressive cavity pumps, cavities are formed between the rotor and stator lobes.
• Each rotation displaces a nearly constant volume of fluid from suction to discharge.

8.2 Leakage and Slip

• All screw pump types rely on small clearances to limit internal leakage (slip).
• As discharge pressure increases, differential pressure across clearances rises, potentially increasing slip.
• Pump efficiency depends on maintaining proper clearances and minimizing wear.
• Material selection and surface finish are crucial to controlling slip over the life of the pump.

8.3 Lubrication Regime

• Three screw and many four screw pumps rely on the pumped fluid for hydrodynamic lubrication.
• Twin screw pumps with timing gears generally avoid direct screw-to-screw contact.
• Progressive cavity pumps rely on a lubricating film between rotor and stator; dry running is highly damaging.

9. Advantages of Screw Pumps Compared with Other Pump Types

When selecting equipment, engineers often compare screw pumps with gear pumps, lobe pumps,

centrifugal pumps, and diaphragm pumps. The main advantages of screw pumps include:

• Low Pulsation Flow: Minimal pressure and flow pulsations, reducing vibration and noise.
• High Efficiency at High Viscosity: Performance improves with higher viscosity up to an optimum.
• Wide Viscosity Range: Multi screw pumps can handle very thin liquids and heavy crude oils in one unit.
• Good Suction Capability: Low NPSH required in many designs, helping prevent cavitation.
• Gentle Handling: Low shear rate is ideal for sensitive chemical or food products.
• Compact Footprint: High pressure performance in relatively small casings.

10. Limitations and Challenges in Screw Pump Operation

Despite their many advantages, screw pumps also have some limitations compared with alternative technologies.

10.1 Solids and Abrasives

• Most multi screw pumps are not designed for large or hard particles.
• Clearances between screws and casing are small; solids can cause rapid wear or blockage.
• Progressive cavity pumps are more tolerant of solids but still affected by highly abrasive media.

10.2 Sensitivity to Dry Running

• Progressive cavity pumps and three screw pumps can suffer severe damage if run dry.
• Dry running destroys the elastomer stator in PC pumps and removes lubrication in internal bearing pumps.
• Monitoring systems, level switches, or variable frequency drives are often used to prevent dry running.

10.3 Temperature and Chemical Compatibility

• Elastomer stators are limited by temperature and chemical resistance.
• High-temperature services require specially selected materials and designs.
• Chemical compatibility charts must be checked for all wetted materials.

11. Selection Criteria: How to Choose the Right Type of Screw Pump

Selecting the best screw pump type for a given duty requires considering fluid properties, system conditions,

and performance requirements.

11.1 Key Parameters

• Flow rate (capacity)
• Discharge pressure and differential pressure
• Viscosity and how it varies with temperature
• Presence of solids or abrasives
• Shear sensitivity of the product
• Temperature and chemical compatibility
• Required NPSH and suction conditions
• System start-stop frequency and operating cycle

11.2 Which Screw Pump Type for Which Duty?

12. Typical Performance Ranges and Specifications

Actual performance ranges vary by manufacturer and specific design, but the following approximate ranges illustrate the

relative capabilities of the main screw pump types.

Note: Temperature ranges are generalized and depend on specific materials and design. Always refer to manufacturer data for exact limits.

13. Installation and Operation Considerations

Regardless of the screw pump type, certain best practices help ensure reliable and efficient operation.

13.1 Piping and Layout

• Keep suction lines as short and straight as possible.
• Use adequately sized suction piping to minimize pressure drop.
• Install isolation valves and check valves where appropriate.
• Provide access for maintenance and removal of pump and motor.

13.2 Drive and Speed Control

• Many screw pumps benefit from variable frequency drives (VFDs).
• Speed control allows flow regulation without bypass valves.
• Lower speeds reduce wear and improve NPSH margin.

13.3 Protection and Monitoring

• Install pressure relief valves on the discharge side.
• Use temperature and pressure sensors to monitor service conditions.
• Employ level switches or dry-running protection as appropriate.
• Regularly check filter or strainer condition in suction lines.

14. Maintenance and Reliability Aspects

Maintenance regimes differ somewhat between screw pump types, but sharing some common principles.

14.1 Progressive Cavity Pumps

• Stator wear is often the main maintenance item.
• Monitoring differential pressure and power consumption gives early warning of wear.
• Use of correct lubrication and seal flushing where required extends life.

14.2 Twin and Multi Screw Pumps

• Correct alignment and lubrication of timing gears and bearings is critical.
• Clearances must be maintained within design limits.
• Regular oil changes (for gearboxes) and vibration monitoring improve reliability.

14.3 Three Screw Pumps

• Fluid cleanliness is essential to avoid damage to internal bearings and screws.
• Filters on the suction side help protect the pumping elements.
• Condition monitoring can include temperature, vibration, and flow verification.

15. Industry Standards and Terminology

Different standards and guidelines address the design and application of screw pumps in various industries:

• API standards for pumps used in oil and gas and refinery services.
• Marine classification society rules for shipboard screw pumps.
• 3-A and EHEDG guidelines for hygienic twin screw pumps in food and pharmaceutical plants.

Common terminology includes:

• Positive displacement screw pump: generic term for screw-based PD pumps.
• Progressive cavity pump: standard name for single screw pumps.
• Multi screw pump: general term for twin, three, four, or more screw designs.
• Axial flow screw pump: emphasizes that the main flow direction is along the screw axis.

16. Summary: How the Main Types of Screw Pumps Differ

In summary, the main types of screw pumps can be distinguished as follows:

• Single screw pumps (progressive cavity):

  • One screw and an elastomer stator.
  • Best for viscous, shear-sensitive, and solids-laden fluids.
  • Common in wastewater, food, and chemical industries.

• Twin screw pumps:

  • Two intermeshing screws, often gear-synchronized.
  • Very versatile, handles a wide viscosity range and multiphase flow.
  • Used in oil and gas, marine, and hygienic food and beverage applications.

• Three screw pumps:

  • One driving screw and two idler screws.
  • Optimized for clean, lubricating fluids at medium to high pressure.
  • Common in lubrication and hydraulic systems.

• Four and multi screw pumps:

  • Multiple screws for high capacity and efficient pressure generation.
  • Mainly used for large-scale oil transfer and pipeline duties.

Knowing the differences between screw pump types—including construction, working principles, advantages,

and limitations—allows engineers, designers, and plant operators to select the most suitable screw pump for their process.

By matching the pump type to the fluid characteristics and operating conditions, users can achieve long service life, high

efficiency, and stable, reliable performance.

```
